DH Robotics VLM Series

Compact circular voice coil actuator with integrated force sensor. Force control precision down to ±0.3 g, resolution down to 20 nm.

DH Robotics VLM Series

Contact us for pricing and availability.

Request a Quote

DH Robotics authorized partner · contact@roboticscenter.ai

View on dh-robotics.com →

Technical Specifications

DH Robotics VLM Series Specs

ModelsVLM-50C-10, VLMF-50C-10 (force control variant)
Peak Force30 N
Continuous Force10 N
Stroke10 mm
Max Speed0.8 m/s
Force Control Precision±0.3 g to ±5 g (model dependent)
Position Repeatability±2 μm (optical) / ±5 μm (magnetic)
ResolutionDown to 20 nm (optical)
Weight650 g
Dimensions104.5 × 55 × 53.5 mm
IP RatingIP40
Voltage24V DC ±10%
CertificationsCE, FCC, RoHS
