OnRobot Gecko SP Gripper

Gecko-inspired adhesive gripper using van der Waals forces for no-mark, no-vacuum gripping. Available in SP1 (1 kg), SP3 (3 kg), and SP5 (5 kg) variants. Grips perforated, shiny, and delicate surfaces. No electronics or air supply needed — true plug-and-play.

OnRobot Gecko SP Gripper

Contact us for pricing and availability.

Request a Quote

OnRobot authorized partner · contact@roboticscenter.ai

Technical Specifications

OnRobot Gecko SP Gripper Specs

ModelsSP1 (1 kg), SP3 (3 kg), SP5 (5 kg)
Payload (max)5 kg (SP5)
Weight0.267–0.318 kg
Dimensions69 × 71 mm
IP RatingIP42
Operating Temperature0–50 °C
Pad MaterialProprietary silicone blend
ActuationPassive (van der Waals adhesion)
Air SupplyNone required
Replacement Time100–1000 ms
