BrandIO-AI Tech
CategoryTeleoperation & Motion Capture
AvailabilityIn stock
Net weight0.593 kg
Dimensions157 × 69 × 80 mm
UMI Dimensions157 × 69 × 80 mm
UMI Weight160 ± 5 g (single hand)
UMI Opening / Closing Angle60°
UMI Maximum Opening Distance155 mm
UMI Connection TypeType-C × 1
UMI RGB Cameras1
UMI RGB Fo V170°
UMI RGB FPS30 Hz
UMI RGB ShutterRolling shutter
UMI Magnetic Encoder Data Rate240 Hz
UMI IMU Accelerometer Range± 16 g
UMI IMU Gyroscope Range± 2000 deg/s
UMI IMU Data Rate240 Hz
UMI Microphone DirectivityOmnidirectional
UMI Microphone Channels2
UMI Microphone Sensitivity-47 ± 4 dB
Wrist Dimensions33.5 × 42.8 × 27.4 mm
Wrist Weight62 ± 5 g
Wrist Camera TypeRGB
Wrist Cameras1
Wrist Fo V170°
Wrist FPS30 Hz
Wrist ShutterRolling shutter
Ego Dimensions160 × 57 × 54 mm
Ego Weight157 ± 5 g
Ego Cameras2 RGB
Ego Camera Distance65 mm
Ego Fo V170°
Ego FPS30 Hz
Ego ShutterGlobal shutter
Ego IMU Accelerometer Range± 16 g
Ego IMU Gyroscope Range± 2000 deg/s
Ego IMU Data Rate240 Hz
Ego Connection TypeType-C × 2
Compute Dimensions119 × 90.3 × 40.5 mm
Compute Weight214 ± 5 g
Compute StorageSSD 1T
Compute Ethernet2.5G × 1
Compute USBType-C × 5 (USB2.0 × 2, USB3.0 × 3)
Sourcehttps://io-ai.tech/en/sensexperience/specs/
