Damiao DM-S2325-1EC
$103.00In stock
Key Specifications
2 N.M
Peak Torque
24 V (Wide-voltage drive supporting 24V—48V power supply.)
Nominal Voltage
1.5 kg
Net weight
5N.M
Nominal Torque
All Specifications
BrandDAMIAO
CategoryActuator & Motor
AvailabilityIn stock
Net weight1.5 kg
ModelDM-2325
Reduction Ratio1:25
Pole Pairs7
Phase Inductance75μH
Phase Resistance0.2915Ω
Maximum Radial Load395N
Outer Diameter28mm
Height77.6mm
Motor Weight172.2g
Encoder TypeIncremental encoder
Control InterfaceCAN@1Mbps(Max)、FD CAN@5Mbps(Max)
Configuration InterfaceUART@921600bps
Control ModesMIT mode Speed Mode Position Mode
ProtectionDrive over temperature protection, protection temperature: 120℃, over temperature motor will exit the "enable mode" Motor overtemperature protection, set according to the use requirements, it is recommended not to exceed 100℃, the motor overtemperature will exit the "enable mode" Overvoltage protection of the motor, which can be set according to the use requirements. It is recommended not to exceed 60V. Overvoltage will exit the "enable mode". Communication loss protection, no CAN command received within the set period will automatically exit the "enable mode" Motor overcurrent protection, set according to the use requirements, it is recommended not to exceed 13A, the overcurrent will exit the "enable mode" Motor under-voltage protection, if the power supply voltage is lower than the set value, exit the "enable mode", the power supply voltage is not less than 15V
Nominal Torque5N.M
Peak Torque2 N.M
Nominal Speed380rpm
Max. No Load Speed560rpm
Nominal Voltage24 V (Wide-voltage drive supporting 24V—48V power supply.)
Nominal Current5A/3.2A
Peak Current13A/7.5A
