3DMakerpro Mole 3D Scanner
3DMAKERPRO

3DMakerpro Mole 3D Scanner

$649.00Backorder
  • Ships from San Francisco
  • Authorized distributor
  • In-house support

3DMakerpro Mole 3D Scanner is a camera built by 3DMAKERPRO for integration into automated systems and research platforms. 3DMakerpro Mole 3D Scanner specifications include Accuracy of 0.05 mm, Resolution of 0.1 mm, and Frame Rate of 10 fps. 3DMakerpro Mole 3D Scanner helps robotics teams reduce integration risk with documented camera parameters

Delivery / Pickup Options
Estimated total$649.00

Key Specifications

0.5 kg
Net weight
141 × 80 × 80 mm
Dimensions

All Specifications

Brand3DMAKERPRO
CategoryCamera
AvailabilityBackorder
Net weight0.5 kg
Dimensions141 × 80 × 80 mm
Frame Rate10 fps
Tracking ModeVisual tracking
Working Distance150–400 mm
Single Capture Range200 × 100 mm
Typical Object Size15–1500 mm
Surface Treatment RecommendationCertain surfaces and materials, such as transparent, reflective, or those likely to require a scanning spray for optimal scanning results.
Light SourceNIR
Color TextureExtended support
USB InterfaceUSB 2.0
Weight390 g
Output FormatOBJ / STL / PLY
Compatible OS (Desktop)Windows 10/11 64‑bit, macOS 12/13
Compatible OS (Mobile)Android 10.0+ / iOS 15.0+ (Extended support)
Minimum PC RequirementsIntel Core i5‑8th, 16 GB RAM, MX250 GPU (2 GB VRAM)
Recommended PC RequirementsIntel Core i7‑8th, 16 GB RAM, NVIDIA 1060 GPU (4 GB VRAM)
Accuracy0.05 mm
Resolution0.1 mm
