WitMotion HWT9073 Sensor
WitMotion

WitMotion HWT9073 Sensor

$845.00Backorder
  • Ships from San Francisco
  • Authorized distributor
  • In-house support

The WitMotion HWT9073 Sensor sensor from WitMotion targets developers building production or prototype robotic systems. WitMotion HWT9073 Sensor specifications include Operating Temperature of -40°C ~ +85°C, Storage Temperature of -40°C ~ +100°C, and Shock Resistance of 20000g. Projects standardize on WitMotion HWT9073 Sensor when sensor accuracy and supportability matter

Delivery / Pickup Options
Order summaryUSD
Merchandise$845.00
Expedited delivery optionIncluded
Shipping (U.S. estimate)$71.34
Estimated total before tax$916.34

Final shipping and tax are calculated from your delivery address at checkout.

Key Specifications

9V ~ 36V (default 12V)
Supply Voltage
0.1 kg
Net weight
144mW
Power Consumption

All Specifications

BrandWitMotion
CategorySensor
AvailabilityBackorder
Net weight0.1 kg
Operating Temperature-40°C ~ +85°C
Storage Temperature-40°C ~ +100°C
Shock Resistance20000g
Protection ClassIP68
Weight121g
Output ContentOn-chip time, 3-axis Accel, 3-axis Gyro, 3-axis Magnetometer, 3-axis Angle
Startup Time≤ 1000ms
Range (Accelerometer)±2g
Sampling Rate (Accelerometer)2kHz
Static Zero Drift (Accelerometer)±25 mg
Temp. Drift (Accelerometer)±0.1 mg/°C
Bias Stability (Accelerometer, 10s Smoothing)XY:3.5ug; Z:5ug
Bias Instability (Accelerometer, Allan)XY:1.5ug; Z:3ug
Range (Gyroscope)±400°/s
Sampling Rate (Gyroscope)50kHz
Static Zero Drift (Gyroscope)±1°/s
Bias Stability (Gyroscope, 10s Smoothing)3.5°/h
Bias Instability (Gyroscope, Allan)2°/h
Measurement Range (Magnetometer)±400 µT
Linearity (±200µT)0.6%
Range (Pitch/Roll)X: ±180°, Y: ±90°
Temp. Drift (Inclination)±0.05°
Range (Yaw)Z: ±180°
Resolution (Accelerometer)0.0005 (g/LSB)
Bandwidth (Accelerometer)5 ~ 256Hz
Resolution (Gyroscope)0.061°/s/(LSB)
Resolution (Magnetometer)13 nT/LSB
Inclination Accuracy0.001°
Resolution (Angle)0.001°
Heading Accuracy (9 Axis, Magnetometer Calibrated)1°
Heading Accuracy (6 Axis, Static)0.1°
Resolution (Yaw)0.001°
