BrandSLAMTEC
CategoryLiDAR
AvailabilityBackorder
Net weight0.6 kg
Data Interface1 x USB-C (No power delivery) 1 x Ethernet (RJ45)
Wireless ConnectionWIFI
Weight505g
Working Temperature0 ℃ ~40 ℃
Maximum Mapping Area>1,000,000 ㎡
RelocationSupport global relocation
Map ContinuationSupport
Map Loading And SavingSupport
Map Localization ModeLaser + vision+ inertial navigation multi-source fusion
Multi Sensor Synchronization MechanismHardware time synchronization
LIDAR Distance Measurementmaximum range 40m@70% reflectivity
Camera SpecificationsBinocular fish eye global camera, supports HDR, FOV 180 °, 6cm base line
Camera Frame RateTypical 10Hz, 15/30Hz can be customized
Maximum Tilt AngleNo requirements, (to ensure the 2D drawing effect, it is recommended that the tilt angle does not exceed 30 °)
