MagicLab MagicDog W Robot
MagicLab offers the MagicLab MagicDog W Robot, a humanoid robot suited to demanding robotics and automation workloads. MagicLab MagicDog W Robot specifications include Standing Dimensions of 670 × 350 × 650 mm, Prone Dimensions of 720 × 500 × 290 mm, and Material Information of Aluminum Alloy + High-Strength Engineering Plastic. MagicLab MagicDog W Robot gives engineers a practical humanoid robot option for lab validation and field rollout
Contact for pricingBackorder
- Ships from San Francisco
- Authorized distributor
- In-house support
Key Specifications
40 kg
Net weight
670 × 350 × 650 mm
Dimensions
37.5 N·m
Maximum Joint Torque
Maximum 10 kg
Payload
6 TOPS
Ontological Computing Power
All Specifications
BrandMagicLab
CategoryHumanoid Robot
AvailabilityBackorder
Net weight40 kg
Dimensions670 × 350 × 650 mm
Standing Dimensions670 × 350 × 650 mm
Prone Dimensions720 × 500 × 290 mm
Material InformationAluminum Alloy + High-Strength Engineering Plastic
Tire Type And Size7-inch Pneumatic Tire
Motor Number16+1 (Head Motor)
Head Rotation Angle≥ 100°
Total Weight22.5 kg (with battery)
Minimum Obstacle Clearance Height< 60 cm
Maximum Slope Angle≤ 40°
Sensors2D LiDAR + Dual Camera + Depth Camera + 4K HD Camera + Fisheye Camera + Ultrasonic Sensors
Audio ModuleOmnidirectional Microphone, Speaker
Touch PerceptionTouch Sensors
Touch FeedbackSupports ≥4 touch methods. The robot's head provides corresponding facial feedback.
Expansion ModulesStandard High-Performance Computing Accelerator Module
Facial Expression Display24
Standby TimeUp to 8 hours (tested)
OTA UpgradeSupport
Operating Temperature Range-5° ~ 40°C
Maximum Joint Torque37.5 N·m
PayloadMaximum 10 kg
Ontological Computing Power6 TOPS
Communication ModuleWiFi 5, 4G Module, BT 5.0
BatteryCapacity: 8200 mAh, Rated Voltage: 29.6 V
Battery Life2-4 h
Motion Speed0-3 m/s
